DS-2CD1T43G0-I 4 MP Fixed Bullet Network Camera
₨ 9,249.00
Offers crisp and detailed visuals with 4-megapixel high-definition resolution
Delivers balanced and clear images in high-contrast lighting with 120 dB Wide Dynamic Range (WDR)
Saves bandwidth and storage space through advanced H.265+ video compression
Built to withstand outdoor elements with IP67-rated protection against water and dust
Simplifies the setup process using Power over Ethernet (PoE), allowing power and data through a single cable
Ensures sharper, clearer images by reducing visual noise with 3D Digital Noise Reduction (DNR) technology
- Description
- Product Specifications
- Size Guide
- Additional information
- Reviews (0)
Description
This camera provides sharp and detailed visuals with its 4-megapixel high-definition resolution, making it ideal for capturing clear footage in various environments. It features 120 dB Wide Dynamic Range (WDR) technology, which allows it to produce well-balanced images even in scenes with strong backlighting or extreme contrast. The device uses advanced H.265+ compression technology to efficiently reduce bandwidth usage and storage requirements without compromising video quality. Built with an IP67-rated enclosure, it is highly resistant to water and dust, ensuring reliable performance in harsh weather conditions. Installation is made simple and convenient with Power over Ethernet (PoE) technology, which allows both power and data transmission through a single cable. Additionally, the camera is equipped with 3D Digital Noise Reduction (DNR), which enhances image clarity by minimizing noise, especially in low-light situations.
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | ICR Cut |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
| Focal Length & FOV | 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°; 6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57° |
| Lens Mount | M12 |
| Aperture | 4 mm F2.0; 6mm F1.6 |
| Supplement Light Range | 50 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850nm |
| Main Stream |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720); 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Video Compression | Main Stream: H.265/H.264/H.264+/H.265+; sub-stream: H.265/H.264 /MJPEG |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11 |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Basic Event | Motion detection, video tampering alarm |
| Dimension | 71.67 × 92.87 × 221.49 mm (2.82" × 3.65" × 8.72") |
| Package Dimension | 234 × 120 × 117 mm (9.21″ × 4.72″ × 4.61″) |
| Weight | 500 g (1.10 lb.) |
| With Package Weight | 670 g (1.48 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | 30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); IC (ICES-003: Issue 6, 2016) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | Ingress protection: IP67 (IEC 60529-2013) |
Additional information
| Brand | |
|---|---|
| Case Type | Bullet |
| Lens Type | Fixed Lens |
| Resolution | 4 MP |
Reviews
There are no reviews yet.
